插值

插值是在两个已知值之间计算中间值的技术,是平滑动画和过渡效果的基础。LayaAir引擎在多个类中提供了插值方法。

MathUtil.lerp 对两个数值进行线性插值:

// lerp(left, right, amount)
// amount = 0 返回 left, amount = 1 返回 right
let value = Laya.MathUtil.lerp(0, 100, 0.5); // 50
let value2 = Laya.MathUtil.lerp(0, 100, 0.25); // 25
let start = new Laya.Vector3(0, 0, 0);
let end = new Laya.Vector3(10, 10, 10);
let out = new Laya.Vector3();
Laya.Vector3.lerp(start, end, 0.5, out); // (5, 5, 5)
let a = new Laya.Vector4(0, 0, 0, 0);
let b = new Laya.Vector4(1, 1, 1, 1);
let out = new Laya.Vector4();
Laya.Vector4.lerp(a, b, 0.5, out);
let startRot = new Laya.Quaternion();
let endRot = new Laya.Quaternion();
let out = new Laya.Quaternion();
Laya.Quaternion.lerp(startRot, endRot, 0.5, out);

沿球面最短弧插值,旋转角速度恒定,推荐用于旋转动画:

Laya.Quaternion.slerp(startRot, endRot, 0.5, out);

图3-1

(图3-1)

特性LerpSlerp
插值路径直线球面弧线
角速度不恒定恒定
性能较快较慢
适用场景位置、颜色、数值旋转
// 将值限制在 [min, max] 范围内
let clamped = Laya.MathUtil.clamp(value, 0, 100);
// 将值限制在 [0, 1] 范围内
let clamped01 = Laya.MathUtil.clamp01(value);
// 循环值(类似取模,但处理负数)
// 例如角度循环:repeat(370, 360) = 10
let repeated = Laya.MathUtil.repeat(370, 360);
// 2D距离
let dist = Laya.MathUtil.distance(x1, y1, x2, y2);
// 两点连线角度
let angle = Laya.MathUtil.getRotation(x0, y0, x1, y1);
// 四舍五入到指定精度
let rounded = Laya.MathUtil.roundTo(3.14159, 2); // 3.14

图5-1

(图5-1)

onUpdate(): void {
let current = this.owner.transform.position;
let target = this.target.transform.position;
let out = new Laya.Vector3();
Laya.Vector3.lerp(current, target, 0.1, out);
this.owner.transform.position = out;
}
let r = Laya.MathUtil.lerp(startColor.r, endColor.r, t);
let g = Laya.MathUtil.lerp(startColor.g, endColor.g, t);
let b = Laya.MathUtil.lerp(startColor.b, endColor.b, t);

线性插值是匀速的,修改 t 值的变化方式可实现缓动效果:

// 缓入(先慢后快)
let easeIn = t * t;
// 缓出(先快后慢)
let easeOut = 1 - (1 - t) * (1 - t);
// 也可使用贝塞尔缓动
let eased = Laya.Bezier.getRate(t, 0.42, 0, 0.58, 1);

关于更完整的缓动动画系统,请参考 Tween缓动系统
